PMC-340B-B (5A (6A), CT Input)

The PMC-340-B Digital Three-Phase Energy Meter is CET’s latest offer for the low voltage power/energy metering market featuring DIN rail mount, high accuracy, multifunction true RMS measurements and a large, easy to read LCD display. The PMC-340-B complies with the IEC 62053-21 Class 1 and IEC 62053-22 Class 0.5S kWh Accuracy Standards for 100A Direct Input and 5A CT Input, respectively. The PMC-340-B comes standard with a LED as well as a Solid State Pulse Output for energy pulsing. The PMC-340-B provides 2MB memory for Data Recording and 3 Digital Inputs for status monitoring, Tariff switching or pulse counting for collecting WAGES (Water, Air, Gas, Electric and Steam) information. The standard RS-485 port and Modbus protocol support allows the PMC-340-B to become a vital component of an intelligent, multifunction monitoring solution for any Power and Energy Management Systems.
