Elster S110 Hot Water Meter
- Single-jet PICOFLUX EP dry dial meter
- Integrated potential-free pulse output
- Warm water up to 90° C
- Permanent / Continuous flow rate of Q3 = 1.6 m3/h
- Meter lengths = 115 and 130 mm
- WaterMark Approved GW-WM-0402430-I01-R02
- NMI Approved (NMI-14/3/48)
- EU-type examination certification: DE-11-MI001-PTB009
The S110 is a single-jet inferential water meter that operates on the velocity principal, where a jet of water enters the measuring chamber and in turn drives a rotor. The velocity of the rotor is proportional to the flow and the only component that is exposed to the water is the rotor. Water movement is transmitted directly by a magnetic coupling to a dry dial register. The S110 is suitable for warm water services with temperatures up to 90C and a maximum working pressure of 1600 kPa. Counter registration is in cubic metres (m3) and litres. Each S110 meter is tested for accuracy before delivery and supplied as standard with a set of male screwed BSP brass connections. An integral non-return valve is provided in the outlet end of the meter. This meter is WaterMark and NMI approved
** Minimum order quantities apply **
